Product Details:
|
| Name: | Steel Grating Plate Ditch Cover | Color: | Silver Or As Your Required |
|---|---|---|---|
| Material: | Carbon Steel Or Asrequired | Surface: | Hot Dip Galvanizing |
| Performance: | Good Drainage Performance And Corrosion Resistance | Transport: | Overseas Shipping |
| High Light: | G505 Steel Grating Cover,Drainage Steel Grating Cover,drain cover steel Plate |
||
In the park square, in order to deal with rainy and snowy weather and solve drainage problems, drainage ditches will be designed, and ditch cover plates will be used in the upper part. On the one hand, to solve the ground drainage problems, on the other hand, to ensure people's safety, galvanized steel grating ditch cover plates will be used. It is welded with load flat steel and cross bars, and the surface is galvanized. The grid structure makes it competent for catchment and drainage, and the effect is very good.
| name | steel grating plate ditch conver |
| material | carbon steel q235 |
| color | silver white or as required |
| surface | galvanizing |
| specifications | common model as the table below,or as your required |
| performance | Good drainage and catchment effect, good compressive performance, corrosion resistance, light structure, convenient installation and disassembly and beautiful appearance |
| transport | shipping |
| origin | China |
|
model |
|
A |
B |
C |
|
|
distance |
cover width |
conver thickness |
Angle steel |
grid |
|
|
BG |
150 |
145 |
20 |
25 |
WA203/1 |
|
BG |
200 |
195 |
20 |
25 |
WA203/1 |
|
BG |
250 |
245 |
25 |
25 |
WA253/1 |
|
BG |
300 |
295 |
25 |
25 |
WA253/1 |
|
BG |
150 |
145 |
25 |
30 |
WA255/1 |
|
BG |
200 |
195 |
25 |
30 |
WA255/1 |
|
BG |
250 |
245 |
32 |
30 |
WA325/1 |
|
BG |
300 |
295 |
32 |
30 |
WA325 |
The performance of trench cover plate is as follows:
The steel grating ditch cover plate has good drainage performance, with a water leakage area of 83.3%, and is not afraid of water corrosion after galvanization. There is no problem for pedestrians to step on it. It can bear ordinary pedestrians and has a long service life.
Park Square drainage ditch, school playground drainage ditch, factory drainage ditch, workshop drainage ditch and other places. In addition to being used as drainage ditch cover plate, steel grating has many application scenarios, such as platform laying in chemical plants, sewage plants, oil refineries and other places.
Kaiheng is a strong manufacturer of steel grating focusing on production, sales and export. We can provide common specifications of spot steel grating for customers at home and abroad, and also support customized steel grating products with individual needs. We have both pressure welding and manual welding.
If you need to customize the drainage ditch cover plate, you can send the design drawing and your requirements to our mailbox info@cnkaiheng.com
