Product Details:
|
| Name: | G908/40/100 Heavy Steel Grid | Color: | Silver White |
|---|---|---|---|
| Material: | Carbon Steel Q235 | Performance: | High Load Ability |
| Surface: | Hot Dip Galvanized Or No Treatment | Standard: | Iso9001:2015 |
| High Light: | G40 Heavy Duty Steel Grate,White Heavy Duty Steel Grate,G40 heavy duty bar grating |
||
Heavy steel grating is a kind of metal plate specially used to bear large loads. This heavy steel grating adopts flat steel with a section of 90mm * 8mm and a cross bar of 8.8mm. It is welded into grid metal plate by pressure welding or manual welding. The appearance and corrosion resistance can be improved after galvanizing treatment. The safety load borne by the steel grating plate of this specification varies according to the mechanical properties borne by different spans, as shown in the figure below:
| name |
G908/40/100 Type Plug-In Heavy Steel Grating |
| color | silver white |
| material | carbon steel Q235 and zinc |
| performance | High bearing performance, corrosion resistance, strong leakage capacity, |
| bearing bar | 90mm*8mm |
| bearing bar pitch(mm) | 40 |
| cross bar pitch(mm) | 100 |
| grill type | G908/40/100FG |
| surface treatment | hot dip galvanizing |
This heavy-duty steel grating is a kind of metal plate that is specialized in solving the unloading problem of large trucks, such as tens of tons or hundreds of tons of trucks. After unloading, the materials will automatically leak from the grid hole to the warehouse for storage, improving efficiency and saving cost. In addition, heavy-duty grating plates will also be used in large ports, docks, working platforms, airports and other scenes. All make use of its excellent bearing performance.
Kaiheng steel grating is a company specializing in the manufacture of steel grating. We can provide customers with personalized customized services and customize heavy steel grating. We can express your needs to our online customer service, and then we can provide you with quotation. The charging mode we adopt is deposit + balance payment. The specific payment and delivery procedures will be communicated again.
